H-80 Series Respiratory High-Flow Therapy Device
Monitor multiple clinical parameters
HFNC, High-flow therapy, AutoFlow, SmartFlow
Provide mixed air and oxygen gases at flow rates up to 80 L/min
Features

H-80 series Respiratory High-Flow Therapy Device is a highly integrated design to meet more needs of clinical treatment. H-80 series Respiratory High-Flow Therapy Device is suitable for patients with spontaneous breathing. It can effectively treat patients by providing a certain flow of heated humidified breathing gas. These patients include patients with humidification therapy, oxygen therapy, endotracheal intubation, and tracheotomy (not for life support).


H-80 series Respiratory High-Flow Therapy Device has accurate temperature control technology, excellent humidification effect, and 7-level humidity compensation to easily deal with various geographical environments. While meeting the treatment effect, it brings the ultimate comfort experience.


With the unique AutoFlow and SmartFlow modes, the device is more intelligent.


*AutoFlow mode: Allows medical staff to easily respond to sudden respiratory events, reducing the pressure on medical care to a certain extent.


*SmartFlow mode: the oxygen flow rate can be switched between inhaling and exhaling so that patients with high flow rates are more comfortable and at the same time use oxygen resources efficiently.


LFlow mode: suitable for children.


HFlow mode: up to meet various clinical needs.


H-80 series Respiratory High-Flow Therapy Device has just added comprehensive monitoring indicators, and the interaction is more convenient and efficient.


The perfect after-sales service engineer team makes your use more worry-free.


The flow rate can reach, meeting the clinical needs.


Precise temperature control, excellent humidification effect, 7-level humidity compensation, easy to deal with various geographical environments.


*Unique and advanced modes: AutoFlow and SmartFlow, which are more automatic and intelligent.


Child-friendly mode: LFlow


High cost-effective, high quality, and perfect after-sales team


The “*” items are only for H-80AS.


Core parameters
ModelH-80ASH-80AH-80M
Adjustment method of oxygen concentration

AutoAutoManual
FlowMonitorable, adjustableMonitorable, adjustableMonitorable, adjustable
Flow range2 - 80 L/min2 - 80 L/min2 - 80 L/min
Oxygen concentration
adjustment range
21%-100%21%-100%21%-100%
Temperature output range29 - 37 °C29 - 37 °C29 - 37 °C
Temperature adjustment gear9 steps adjustable9 steps adjustable9 steps adjustable
Screen size3.5 inches3.5 inches3.5 inches
Trend review function1 day; 3 days; 7 days1 day; 3 days; 7 days1 day; 3 days; 7days
Oxygen concentrationMonitorable, adjustableMonitorable, adjustableMonitorable
TemperatureMonitorable, adjustableMonitorable, adjustableMonitorable, adjustable
sPEEPMonitorableMonitorableMonitorable
Respiratory rateMonitorableMonitorableMonitorable
Automatic reminder of filter replacementYes, settableYes, settableYes, settable
Automatic water filling functionYesYesYes
AutoFlowYes//
SmartFlowYes//
Humidity compensation7 steps adjustable7 steps adjustable7 steps adjustable


For more details contact: intl_hbu@bmc-medical.com
