G3 BPAP System (G3 LAB)

Model No:G3 LAB

Key Features:BPAP System, Bi-level CPAP System, G3 LAB, Respiratory Insufficiency, COPD, Target Tidal Volume Function

Description: BMC G3 LAB is a bi-level device to be used in sleep lab for treatment and titration of patients with sleep apnea and/or respiratory insufficiency.

Detail

BMC G3 LAB is a bi-level device to be used in sleep lab for treatment and titration of patients with sleep apnea and/or respiratory insufficiency.

Features

Effective Performance
  • S/T Mode
    The device follows patient's spontaneous breathing. However, if there is no inhalation for a certain period of time, the decive will give a forced ventilation to ensure the minimum ventilation volume.
  • Target Tidal Volume Function
    According to the patient's need, G3 can set the Target Tidal Volume and the device will automatically adjust the pressure support level to reach the preset tidal volume, so as to ensure better ventilation effect. According to the patient's need, G3 can set the Target Tidal Volume and the device will automatically adjust the pressure support level to reach the preset tidal volume, so as to ensure better ventilation effect.
  • Auto Leak Compensation
    The device detects the air leakage during treatment in real time and adjusts the baseline to ensure correct triggering and related functions.
  • Inspiratory time control
     Ti min and Ti max could be set independently, avoiding insufficient ventilation due to short inspiratory time. At the meantime, cases can be prevented where expiratory sensitivity is unable to meet due to large leak.
  • PM2.5 filter box
     Extra sensitive users can filter finer dust and allergens with the PM2.5 filter box.
  • SpO2 sensor
     Finger sleeve type
     Finger clip type
Intelligent comfort features
  • Inspiratory / Expiratory sensitivity
     8 grades of I Sens and E Sens optimize the compliance of the device with the patient.
  • Pre-heat
    The G3 series has a pre-heat feature, to warm your humidifier water up for ultimate comfort during cold, dry weather.
  • Integrated heated tubing with intelligent Auto Humidity control
    Integrated heated tubing with intelligent Auto Humidity control gives G3 maximum moisture while ensuring condensate in the tubing is not an issue.
  • Excellent silence performance
    BMC uses multi-stage noise reduction technology to ensure noise performance under 26 dB(A).
Modern design with a user friendly interface
  • All new humidifier design keeps the G3 compact and attractive.
  • Innovative PUSH water chamber is simple to use.
     Water can be added without removing the water chamber for ease of use.
  • Humanized UI Design
     One button access to frequently used features
     A 3.5" screen displays real-time data and waveform feedback in full color
  • Accessory and supply reminder keeps your treatment healthy and effective.
  • G3 has a clock, temperature and humidity monitor on stand-by, multi-purpose for convenience.
Powerful data transfer / retrieval solution
  • SD Card
  • Cellular
  • WiFi
  • iCode / iCode QR / iCode QR+
Various way of reviewing Sleep Report
  • Quick Report through Device Screen
  • PAP Link App
  • Cloud Platform
  • iCode web version (www.bmc-icode.com)
  • RESmart nPAP Data Analysis Software (PC software)
  • RESmart Software web version (www.icodeconnect.com/quick/info)
Complete optional accessories

G3 adopts a series of complete accessories to meet different usage scenarios and needs
  • SpO2 Kit
  • Cellular / WiFi Module
  • Integrated Heated Tubing
  • PM2.5 Filter Box

Configurations

Model G3 LAB
Working mode & functions CPAP, AutoCPAP, S, AutoS, T, Target Tidal Volume
Advanced event detection CSA Detection
Comfort features
Auto Ramp
Auto Humidifier
Auto Heated Tubing
Reslex (Expiration Pressure Release)
Smart C
Smart A
Smart B
Data
SD Card
RESmart nPAP Data Analysis Software
iCode
iCode QR
iCode QR+
PAP Link App
iCode Web Version
Built-in cellular / WiFi module
Cloud Platform
